導電布製シールド用ガスケット

用 途 用途
制御盤、OA機器、パソコン、コンピュータおよび周辺機器、無線機器、医療機器、その他電子応用機器等のEMI対策。
特長 特長
  1. 特殊構造で製作し、芯材に高性能ウレタンフォームを使用しているため面圧がソフトでありながら復元弾性力が非常に高く、長時間圧縮した後でも接触抵抗値を低く保ちつづけます。
  2. 表面が滑らかで柔軟性に富んだ導電性繊維のため、接面する相手形状によくフィットします。
  3. 粘着テープが貼り付けられているため、キャビネット等に容易に取付可能です。
  4. 難燃タイプのRoHS対応品、UL認証品も取り揃えています。
  5. 右写真の形状のように、使用状態の長さにダイカット、別の剥離紙に貼り直して、必要な長さにカット(アレイ方式)や打ち抜きの加工を致します。
材質 材質
めっき：ニッケル＋銅＋ニッケルめっき　
使用可能温度：－20℃～+80℃　
M4の粘着力：0.8kgf/25mm　
●布の材質
導電リップストップ布、導電DTY布
〔特殊品〕アルミ箔
●難燃タイプ
UL V-0認証品(NB)

標準リストはこちら
