1.These products can be attached to panel boards, distribution boards, control boards, operation boards and so on in order to fix instruments and components without making holes as the structural materials.
2. No need for the use of intermediate plate for fixing instruments by using these products such as angle, channel and so on.
3. Reduction of the fixing process for intermediate plate with these channels
4. It can be used for the attachment of instruments and the supporter to ducts, wires, bus bars, piping and so on.

1.Design change, expansion and remolding of fixing instruments and components can be made easily without any restrictions.
2. The delivery lead time can be reduced to do steel metal working for boxes and internal wiring separately.
3.Assembly and wiring can be made with layout drawings of each instruments and components before the completion of the boxes.
4. The working processes can be improved by the use of accessories for these channels.

Materials

SPHC steel and Stainless steel 304 can be provided by the customers’ request.
